Accurate detergent & rinse aid peristaltic dosing pumps with dosing setup by fascia controls
Easy clean parallel wash and rinse arm assembly
Drain pump as standard
Optional surface scrap tray filters
Supplied with two open cup/glass racks & cutlery insert as standard
AMH - Undercounter
AMH50D
Width x Depth x Height mm
580 x 610 x 810mm
Feet Height
10mm-20mm
Basket size
500x500mm
Maximum useable height
340mm
Door Opening
365mm
Cycle times
90/180 Seconds
Water consumption per cycle
2.5 Litres
Wash tank capacity
20 Litres
Phase - Options
Single/3-Phase
Power – Single Phase Options
2.6kW(13Amp),4.5kW(20Amp), 6.5kW(30Amp)
Power – Three Phase
6.5kW(16Amp)
Detergent pump
Peristaltic - non timed
Rinse aid pump
Peristaltic - non timed
Drain pump
Yes
Breaktank
No
Water supply pressure
2 to 4 Bar
Body Construction
Single Skin
Door/Hood Construction
Double Skin
Scrap Trays
Optional
Internal Rinse Booster Pump
N/A
Number Of Cycles
2
Total Maximum Load(as supplied)
6.5kW(30Amp) - Single Phase
You can access all spares relating to this machine via the following link
