MC300 Modular Icemaker
W 1250 x D 580 x H 848mm Production (24 hours) 300kg Drain height 73mm (modular unit only) Water consumption (air cooled) 2.6 litres/kg Water consumption (water cooled) 14.3 ltres/kg Gross weight 152kg Power 2.6kW 240V, Single phase, 32 amp Require water supply pressure between 1 and 6 bar
Features
1 year warranty WRAS approved *Optimum ice production is at an ambient temperature of 21°C. Higher temperatures will dramatically reduce ice production*
1 year warranty WRAS approved Produces dense, slow melting cubes, standard 18 gram cubes, 13 or 33 gram cube available to special order Extra cold ice produced at -25°C Capable of operating in ambient temperatures of between 10°C and 43°C Supply water temperature between 3°C and 32°C Available to special order as water cooled version at the same price * To produce ice of good quality all machines must have water softeners fitted to the water supply and must be of sufficient capacity and maintained in good order *
Maidaid
MC300
Width x Depth x Height mm
1250 x 580 x 848mm
Production in kg over 24hours#
300kg
Storage capacity
Bin dependent
Cooling system
Air or Water
Ice type
Cube
Cube size
18g / 13g / 33g
Refrigerant
R404A
Power voltage/phase/Hz
240 / 1 / 50
Power watts / Amps
2600W (32A)
Water consumption L/Kg
A, 2.6 / W, 14.3
Water supply pressure
1 to 6 bar
Ambient temperature between
10ºC / 43ºC
Water supply temperature between
3ºC / 32ºC
Bin type
MT350
Weight nett / gross Kg
152 / 178kg
