MVM900
- W 770 x D 550 x H 805mm
- Production (24 hours) 400kg
- Drain height 40mm (modular unit only)
- Water consumption (air cooled) 1.8 litres/kg
- Water consumption (water cooled) 13 litres/kg
- Gross weight 124kg
- Power 3.0kW
- 230V, Single phase, 32 amp
- Require water supply pressure between 1 and 6 bar
- 1 year warranty
- Produces a mini 7 gram cube suitable for fast food outlets serving carbonated drinks
- Capable of operating in ambient temperatures of between 10°C & 44°C
- Supply water temperature between 3°C & 32°C
| Maidaid |
MVM900 |
| Width x Depth x Height mm |
770 x 550 x 805mm |
| Production in kg over 24hours# |
400kg |
| Storage capacity |
Bin dependant |
| Cooling system |
Air or Water |
| Ice type |
Cube |
| Cube size |
7g |
| Refrigerant |
R452A |
| Power voltage/phase/Hz |
230 / 1 / 50 |
| Power watts / Amps |
3000W (32A) |
| Water consumption L/Kg |
A, 1.8 / W, 13 |
| Water supply pressure |
1 to 6 bar |
| Ambient temperature between |
10ºC / 43ºC |
| Water supply temperature between |
3ºC / 32ºC |
| Bin type |
M240PE, MT200, MT350, MDR100 |
| Weight nett / gross Kg |
113 / 124kg |
You can access all spares relating to this machine via the following link
