SLIM195E
- W 560 x D 620 x H 660mm
- Production (24 hours) 210kg
- Drain height 43mm
- Water consumption (air cooled) 9.2 litres per hour
- Gross weight 78kg
- Power 2.84kW
- 230V, Single phase, 16 amp
- Require water supply pressure between 1 and 5 bar
- Environmentally friendly gas
- 1 year warranty
- 560mm wide unit designed for small spaces
- Soft touch control panel
- Standard cube 10 gram 22 x 22 x 24mm
- Hydrocarbon with zero environmental impact
- Half cube 6 gram & large cube 17 gram options available
- Vertical evaporation design
- Excellent service accessibility
- Capable of operating in ambient temperatures of between 10°C & 40°C
- Supply water temperature between 5°C & 35°C
| Maidaid |
Slim195E |
| Width x Depth x Height mm |
560 x 620 x 660mm |
| Production in kg over 24hours# |
210kg |
| Storage capacity |
Bin dependant |
| Cooling system |
Air |
| Ice type |
Cube |
| Cube size |
10g |
| Refrigerant |
R290 |
| Power voltage/phase/Hz |
230 / 1 / 50 |
| Power watts / Amps |
2900W (16A) |
| Water consumption L/Hr |
A, 9.2 |
| Water supply pressure |
1 to 5 bar |
| Ambient temperature between |
10ºC / 40ºC |
| Water supply temperature between |
5ºC / 35ºC |
| Bin type |
MSB105, MSB155, MSB255 |
| Weight nett / gross Kg |
68 / 80kg |
