Maidaid C Range Pass Through
2 Year Warranty on all C range pass through machines
C2011
C2011 gravity waste version
500 x 500mm rack
W640 x D745 x H1500mm
C Range Hood
C2011 / C2011D
Width x Depth x Height mm
640 x 745 x 1500mm (inc feet)
Feet Height
165mm to 225mm
Basket size
500 x 500mm
Maximum useable height
435mm
Door Opening
460mm
Cycle times
70/90/120 Seconds
Water consumption per cycle
2.0 Litres
Wash tank capacity
15 Litres
Phase - Options
Single/3-Phase
Power – Single Phase Options
4.5kW(20Amp),6.5kW(30Amp)
Power – Three Phase
6.5kW(16Amp)
Detergent pump
Peristaltic - Non Timed
Rinse aid pump
Peristaltic - Non Timed
Drain pump
C2011 - No
C2011D - Yes
Breaktank
Yes
Water supply pressure
2 to 4 Bar
Body Construction
Single Skin
Door/Hood Construction
Single Skin
Scrap Trays
Yes
Internal Rinse Booster Pump
Yes
Number Of Cycles
3
Total Maximum Load(as supplied)
6.5kW(30A) – Single Phase
C2011D
C2011D pumped waste version
500 x 500mm rack
W640 x D745 x H1500mm
C2035WS
C2035WS with internal softener
500 x 500mm rack
W640 x D745 x H1500mm
C Range Hood
C2035WS
Width x Depth x Height mm
640 x 745 x 1500mm (inc feet)
Feet Height
165mm to 225mm
Basket size
500 x 500mm
Maximum useable height
435mm
Door Opening
460mm
Cycle times
70/90/120 Seconds
Water consumption per cycle
2.0 Litres
Wash tank capacity
15 Litres
Phase - Options
Single/3-Phase
Power – Single Phase Options
4.5kW(20Amp),6.5kW(30Amp)
Power – Three Phase
6.5kW(16Amp)
Detergent pump
Peristaltic - Non Timed
Rinse aid pump
Peristaltic - Non Timed
Drain pump
Yes
Breaktank
Yes
Water supply pressure
2 to 4 Bar
Body Construction
Single Skin
Door/Hood Construction
Single Skin
Scrap Trays
Yes
Internal Rinse Booster Pump
Yes
Number Of Cycles
3
Total Maximum Load(as supplied)
6.5kW(30A) – Single Phase
C2035WSHR
C2035WSHR with heat recovery
500 x 500mm rack
W640 x D745 x H2200mm
